What’s a Matrix Switch and Why Your A/V System or Home Theater Needs One

Television, The tube. This life-changing picture box has become an essential part of our daily lives. There's an average of two and half TVs in every household. While businesses from sports bars and dealerships to medical facilities and malls can have anywhere from six to thirty TVs. All used for different purposes like entertainment. monitoring, gaming, and digital signage. Wonder what makes connecting all these TVs possible?-----The HDMI matrix Switcher

Why your A/V system or Home Theater needs one?

The HDMI Matrix switcher which can switch the multi-channel signal from the inputs to any one channel in the outputs, and the output are independent of each other.

When an entertainment system is comprised of multiple video components, such as set-top boxes, Blu-ray players and media servers, it makes sense to share all that content with every TV in your house. The common way to do this is through HDMI Matrix Switcher.

For a modest home theater system, the HDMI ports on the back of your home theater receiver act as a matrix switch. They allow you to plug in several HDMI sources and output each source to your display (TV or projector). Some AV receivers even allow two HDMI outputs for two independent audio/video zones. but those tend to be very expensive receivers. if you want your video sources to be available on displays all over your house (or if you have multi-display room ) then you need a separate matrix switch. and it also offer analog and digital audio de-embedding for sound. Make sure the one you choose has the proper set of audio connections that matches the video/HDMI matrix switcher's style of audio connections.

Different types of HDMI Matrix Switcher

There are a multitude of options when it comes to HDMI matrix switchers on the market. The primary goal is getting the matrix switcher that best suits your budget and application needs to fit the overall scheme of the AV design.

Some important aspects when searching for an HDMI matrix switcher are determining the number of TVs and sources you have. This tells you whether you need a 4x4,  8x8, 16x16, or an HDBaseT matrix switcher. The numeric combination represents “sources x displays.” So a “4x4” matrix switcher means  four sources / four displays. Now if the cable runs needed exceed 40 feet, you'll want to consider using HDBaseT technology. HDBaseT matrix switchers use category cables to send the audio and video signals long distances via baluns/receivers, with limitations typically to 328 feet.
